SWITCH 10P TP-LINK OMADA ES210GMP GIGA 8 POE+ ADM EAN: ES210GMP

CARACTERÍSTICAS DE HARDWARE Interfaz • 8× 10/100/1000 Mbps PoE+ RJ45 Ports (support 802.3af PoE and 802.3at PoE+) • 1× 10/100/1000 Mbps RJ45 Port • 1× Gigabit SFP/RJ45 Combo Port • Auto-Negotiation/Auto MDI/MDIX Cantidad de Ventiladores Fanless Instalación • Desktop • Wall Mount Bloqueo de Seguridad Físico v Fuente de Alimentación DC Power Adapter (Output: 53.5V DC / 2.43A) Puertos PoE (RJ45) • Standard: 802.3af PoE and 802.3at PoE+ compliant • PoE Ports: 8 ports • PoE Budget: 123W available for all PoE+ ports, 30W max per port • PoE Auto Recovery‡ • Up to 250m PoE transmission distance** Dimensiones 8.2×4.9×1.0 in (209×126×26 mm) Surge Protection ±6kV RENDIMIENTO Capacidad de Conmutación 20 Gbps Tasa de Reenvío de Paquetes 14.88 Mpps Tabla de Direcciones MAC 8K Memoria del Buffer de Paquete 4 Mbit Jumbo Frame 15 KB CARACTERÍSTICAS DE SOFTWARE Calidad de Servicio • Port-based/802.1p/DSCP QoS • 8 Priority Queues • Priority Schedule Mode - WRR (Weighted Round Robin) • Queue Weight Config • Bandwidth Control - Port-Based Rating Limit • Storm Control - Multiple Control Modes (kbps/pps) - Broadcast/Multicast/Unknown-Unicast Control? Características L2 • Static Link Aggregation • Loop Prevention / Loopback Detection • Flow Control - 802.3x Flow Control • Mirroring - Port Mirroring - One-to-One - Many-to-One - Ingress/Egress/Both • Port Statistics - Port Mirror Status - Traffic Statistics • 802.1ab LLDP Multicast L2 • IGMP Snooping - IGMP v1/v2/v3 Snooping - Fast Leave VLAN • MTU VLAN • Port-Based VLAN • 802.1Q Tag VLAN - Max 32 VLAN Groups - 4K VID Método de Transmisión Store-And-Forward GESTIÓN Omada App Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. Gestión Centralizada • Omada Cloud-Based Controller • Omada Hardware Controller • Omada Software Controller Acceso a la nube Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller. Aprovisionamiento sin contacto Yes. Requires the use of Omada Cloud-Based Controller Funciones de gestión • Web-based GUI • DHCP Client • Cable Diagnostics • Automatic Device Discovery† • Batch Configuration† • Batch Firmware Upgrading† • Unified Configuration† Otros Certificaciones FCC, CE, RoHS Contenido del Paquete • ES210GMP • Power Adapter • Installation Guide • Rubber Feet Factores Ambientales • Operating Temperature: 0?~40? (32?~104?) • Storage Temperature: -40?~70? (-40?~158?) • Operating Humidity: 10%~90% non-condensing • Storage Humidity: 5%~90% non-condensing
